Laminated glass
LAYERED PANES HAVE UNLIMITED APPLICATION POSSIBILITIES
In order to adapt their construction to various requirements the standard range of symmetrically built laminated annealed Float panes is insufficient, therefore PRESS GLASS extended its range with its range with its own production of layered panes.
PRESS GLASS possesses a world-class Benteler glass laminating line and Scholz autoclave, which are the guarantee of products of the highest quality.
Market offer
TYPES OF PRODUCTS OFFERED:
– laminated panes
– laminated safety panes
– laminated protective panes
Layered panes are executed in all the combinations permitted by the production process possibilities. Layered safety panes are the panes among all possible combinations, which fulfil the requirements of one of the classes given in Standard EN 12600.
Correspondingly the construction of layered protective panes satisfies the requirements of Standard EN 356.
SAFETY AND PROTECTIVE LAYERED PANEL CONSTRUCTIONS OFFERED
|
Two-layered laminated pane construction |
|||
| Min. glass thickness from the side of action of given destructive factor | Minimal quantity of foil layers expressed in foil of thickness 0.38mm | Min. glass thickness from the side free of action of given destructive factor | Class EN 12600 |
| 3 | 1 | 3 | 2B2 |
| 3 | 2 | 3 | 1B1 |
WINDOW DESIGNS PROVIDED PROTECTIVE LAYER
| Two-layered laminated pane construction | ||||
| Nominal thickness [mm] | Min. glass thickness from the side of action of given destructive factor | Minimal quantity of foil layers expressed in foil of thickness 0.38mm | Min. glass thickness from the side free of action of given destructive factor | Class EN 356 |
| – | 3 | 2 | 3 | P1A |
| – | 4 | 2 | 4 | P2A |
| – | 4 | 4 | 4 | P3A |
| – | 4 | 4 | 4 | P4A |
| – | 4 | 6 | 4 | P5A |
| Multi-layered laminated pane construction | ||||
| 15,04 | – | – | – | P6B |
| 23,04 | – | – | – | P7B |
| 27,80 | – | – | – | P8B |
MOST IMPORTANT APPLICATIONS
POTENTIAL OF PRESS GLASS PRODUCTION LINE
| Max. packet thickness [mm] | 100 | |||||
| Max. format measurements [mm] | 3200 x 7000 | |||||
| Min. format measurements [mm] | 250 x 500 | |||||
|
Max. weight [kg] – of packet – component panes |
–
1000 500 |
|||||
GLASS TYPES AVALIABLE FOR LAMINATING
– colourless and coloured in mass
– with low emission anti solar and selective coatings
– chosen ornaments decoration
APPLIED FOR FOIL TYPES
– colourless
– matt
– acoustic
– colour
ADVANTAGES OF LAMINATED PANES
COMPARISON OF ACOUSTIC PROPERTIES OF SELECTED MONOLITHIC
AND LAYERED PANES WITH SIMILAR THICKNESS, BASED ON EN 12758 and 12354-3
| Structure [mm] | Acoustic insulation indicator and adaptive indicators [dB] | |||
| Rw | Ctr | C | ||
| 6 | 31 | -3 | -2 | |
| 6,4 (VSG 33.1) | 32 | -3 | -1 | |
| 8 | 32 | -3 | -2 | |
| 9,5 (VSG 44.4) | 34 | -3 | -1 | |
